20DP Gears are compatible with the REV ION System and come in a wide range of sizes and bores. This gear features a 15T spline bore for use with 15T spline shaft and motors like our NEO 2.0 Brushless Motor. A notch on the bore provides an easy visual...

The 15T Spline Shaft is a solid stainless steel shaft sized at 480mm for long span applications or to be used as stock to cut custom length shafts. Its 15 tooth involute spline profile features an 8mm outer diameter and interfaces with the REV ION...

The 15T Spline to 1/2in Hex Adapter provides a simple and reliable way to integrate motors with a 15T spline output shaft into mechanisms designed around 1/2in rounded hex. This adapter is ideal for teams looking to pair the NEO 2.0 Brushless Motor...

The MAXSpline Grommet provides a simple way to route wires through MAXTube while preventing abrasion against bare aluminum. Made from pliable 60A rubber, it press-fits into the MAXSpline Bore on MAXTube with a 1/8 inch wall, creating a clean pass-through...

The MAXPlanetary 1:1 Brake Cartridge is a drop-in, self-contained module that instantly adds a reliable bi-directional unpowered hold for any MAXPlanetary gearbox. Designed around the principles of a sprag clutch, sometimes referred to as a torque diode,...

The REV Through Bore Encoder V2 provides precise, reliable shaft position measurement with both incremental (ABI quadrature) and absolute (pulse-width) outputs. Its ½" hex through bore mounts easily within common FRC/FTC mechanisms, and the...

The SPARK MAX Data Port Breakout Board makes it easy to connect external sensors to the SPARK MAX Data Port. For additional information on the SPARK MAX Data Port, please take a look at the SPARK MAX User's Manual. Analog Input Issue - Affects Rev. A...

REV Robotics custom ATO sized auto-resetting breakers are designed to give reliable protection for FRC robot actuators.  These custom developed breakers adhere to SAE Standard J553 and will give consistent performance even after hundreds of breaker...

MAXSpline Bearing Blocks are compatible with the REV ION System. Quickly add bearing support to any location on REV ION extrusion without the need for precision machining. Can also be used in a west coast style drivetrain to add center wheel drop while...

These MAXPlanetary Input Couplers are compatible with the REV ION System. The MAXPlanetary 1/2in Hex Input Coupler (REV-21-2110) attaches to the end of a hex shaft, securely held in place by a screw, enabling the MAXPlanetary to be powered by a hex shaft...

MAXSpline Shaft Endcaps are compatible with the REV ION System and transform your MAXSpline Shaft extrusion into a live axle driven by a 1/2in Hex shaft. MAXSpline Shaft Endcaps come in two different materials: a durable plastic version and an upgraded...

Tube Nuts for 3/4in Dead Axle Tube are compatible with the REV ION System. This #10-32 tube nut presses into the end of the tube and supplies a tapped hole for easy mounting. Typically used with dead axle applications. The left-hand threaded...

#10-32 Ball Joint Rod Ends are compatible with the REV ION System. Right-hand threaded rod ends tighten when turned clockwise while left-handed threaded rod ends tighten when turned counterclockwise.  Specifications Type: Stud-type Rod...

The MAXSpline Shaft Bearing Block Kit and MAXSpline Bearings are compatible with the REV ION System and are perfect for using MAXSpline Shaft in a live axle application or any other similar sized rotational needs. Effortlessly mounting to REV's hole...

MAXHubs are compatible with the REV ION System and provide a way to transfer torque to a MAXSpline bore from shafts of various shapes and sizes. Other hub variants allow for other bores or mount holes to populate within an existing MAXSpline...

MAXSpline Brackets are compatible with the REV ION System and are designed to mount to pieces of MAXTube - 2x1 - MAX Pattern while maintaining proper pattern spacing. Specifications Material: Aluminum 5052 Weights: MAXSpline Bracket - Stacked: 35g (0...

1/2in Hex Shaft Spacers are compatible with the REV ION System and can be used on the shaft as a spacer; they also work as spacers between wheels and sprockets, etc. Specifications Material: POM (Acetal/Delrin) OD: 0.72in Weights &...

The 550 Motor Pinions are used for transferring power from a 550 class motor, like the HD Hex Motor or NEO 550, to a mechanism. These pinions come in four different types. The 32DP pinion gear is compatible with 32DP gears,the UltraPlanetary Pinion is...

RT25 pulleys pair with RT25 belts to create a power transmission system that matches the exact pitch of #25 chain while aligning with the 1/2in ION Build System pitch. This makes RT25 a drop in alternative to #25 chain and sprockets with the advantages...

RT25 Belts are toothed belts with a 1/4in pitch are compatible with the REV ION System. These belts are comparable in strength to the belts that teams are used to using while working on the pitch of the ION build system. Belts are lighter than...

The NEO Pinions are used for transferring power from a NEO Brushless Motor or something with a similar matching shaft to a mechanism. These pinions come in three different types; either gear, sprocket, or pulley. The pinion gears are compatible with 20DP...

The Elevator Bearing Blocks family offers reliable, versatile solutions for creating linear motion in elevator systems using MAXTube. Both the original Elevator Bearing Block and the Clamping Elevator Bearing Block provide teams with the flexibility to...

MAXTube Endcaps are designed for seamless integration with the REV ION System, providing a simple and effective solution for joining two or more MAXTube extrusions. These endcaps are pre-tapped for #10-32 hardware, ensuring quick assembly and reliable...

The MAXLift #25 Chain Attachment Plate is a durable yet lightweight aluminum bracket designed for seamless use with the REV ION system within the MAXLift family of products. It simplifies mounting and assembly for elevator and lift systems. Featuring...

3/16in Rivets are compatible with the REV ION System are perfect for a variety of applications where a strong, permanent joint is required. Place the rivet into a hole from a single side (a “blind” hole) and then use a rivet...

Steel hardware of the appropriate size to work with the REV ION System. Length measured from tip to underside of screw head. Documentation ION Build System Guide Hardware Basics Onshape Application Examples Product...

Steel hardware of the appropriate size to work with the REV ION System. Length measured from tip to underside of screw head. Documentation ION Build System Guide Hardware Basics Onshape Application Examples Product...

ION Servo Accessories allow for easy integration into REV ION System. Mount a hobby sided servo, such as the REV Smart Robot Servo, on a 1/2in pitch. Using the adapters, you can convert a servo to a 1/2in Hex shaft for use with all other...

The 8mm Shaft Spacer is compatible with the REV ION System and is a convenient way to space pinions and gears along the shaft of the NEO Brushless Motor. The 8mm Shaft Spacer is bigger than the 1/2in Hex Adapter and can help keep...

#10-32 Shaft End Screw V1 and V2 are compatible with the REV ION System and are used to retain parts on any ION hex shaft instead of shaft collars. 1/2in Rounded Hex Shafts in various lengths are available and come tapped with #10-32 holes. The...

The 3in MAXSwerve Module – 15T Spline Input Kit is designed to adapt the REV NEO 2.0 Brushless Motor or Kraken X60 for use with the 3in MAXSwerve Module. This kit provides the necessary gearing and hardware to integrate a 15T spline drive motor...

The MAXPlanetary Kraken X44 & Minion Input Kit is a comprehensive solution for adapting Kraken X44 or Minion motors to the MAXPlanetary system. This kit includes the [REV-21-4444] MAXPlanetary Kraken X44 & Minion Adapter Plate, designed with...

GT2 3mm Pitch Belts are compatible with both the REV ION System and the REV DUO System. These belts go hand in hand with GT2 timing pulleys. Use belts and pulleys in tight to fit areas where adjustment is difficult. Specifications Pitch: 3mm Width: 9mm...

Bearings 15T Spline Bearing - Flanged - 1.125in OD - 4 Pack (REV-21-3294-PK4) Featuring a 8mm internal diameter and a 1.125in outer diameter, this bearing is designed to fit into a MAXSpline bore while supporting a 15T Spline shaft. The flange adds a way...

These ION Motor Brackets are compatible with the REV ION System. The ION UltraPlanetary Face Mount Bracket (REV-21-2046) allows for easy mounting of our UltraPlanetary Gearbox to any of our MAXTube products. Each plate features 2x #10-32 tapped inserts...

The MAXLift Bearing Blocks are integral components of the MAXLift system, providing teams with a robust and space-efficient solution for building high-performance elevator assemblies. With the main blocks being designed around billet aluminum...

The 3in MAXSwerve Spiky Wheel - Hub and Tread Bundle includes everything needed to outfit your MAXSwerve-equipped robot with Spiky wheels for enhanced performance. The bundle contains four (4) balanced aluminum hubs, eight (8) Spiky split treads, and...

The 3in MAXSwerve Spiky Wheel Aluminum Hub is a durable replacement or backup hub designed specifically for the MAXSwerve system. Pair it with a fresh Spiky Wheel Tread and #10-32 3/8in button head screws for a high performance drivetrain. For quick full...

The 3in MAXSwerve Spiky Wheel Tread is designed for superior grip and performance in competitive robotics. Made from injection-molded thermoplastic polyurethane (TPU) with a Shore A durometer of 95, this tread offers an improved coefficient of friction...

The Aluminum Angle 0.74in x 0.74in is a robust and lightweight solution for attaching and connecting components in your robot design. Made from the same clear anodized aluminum as MAXTube, this angle iron-shaped extrusion is designed for compatibility...
